Features
- Non destructive measurement of particles on parts
- Counts particles(0.3-5.0μm＆0.1-5.0μm）
- Monitors the particle evolution as a function of time
- Constant clean air flow through HEPA filter unit
- Forced air stream impact for particles removal
- Customized fixtures for diverse applications
- Fixture for particle collection and analysis
- Simple operation in any clean environment
Applications
- Cleanliness of parts and materials
- Comparison of cleaning methods
- Equipment and machine parts
- Carriers, Holders, cassettes, boxes etc.
- Clean rooom garments
- Clean room consumables
Additional Details
- Only clean air & electricity required for operation
- Software control of functions and settings
- 7 inch touch-screen interface
- User programmable testing procedures
- Data retrieval to USB drive
Dimensions
- Foot print 90×50 cm、（130cm with optional shelf)
- Polished stainless steel chamber
- Chamber door opening 274×244 mm
